Screen Size: 86 inch
Touch Type: Infrared touch technology
Panel Type: TFT LCD Module with DLED Backlight
ouch Tool: Finger/Nontransparent Objects
Number of Touch: Up to 20 Point Multi-touch
Response Time: 8ms (over 90% Area), ≤10ms
Accuracy: ±1mm(over 90% Area)
Valid Touch: 2mm
Touch Heigh: ≤2.5mm
Anti-Light Interface: Anti-Dazzle Tempered Glass
Surface Hardness: 8H
Touch Resolution: 31767 × 32767
Resolution: 3840 (H) x 2160 (V), 4K UHD
Display Area: 1896mm (H) x 1067mm (W)
Aspect Ratio: 16:9
Brightness: 450 cd/m²(dyn.)
Color: 1.07 Billion (10 bits)
Viewing Angle: 178° (H); 178° (V)
Writing mode: Finger + Pen(attaches magnetically)
Backlight Life: ≥50,000 hrs
Refresh Rate: 60 Hz
86 Inch Interactive Digital Whiteboard (RAM-8GB, SSD-128GB)
{{ $trans('storefront::product.left_in_stock', { count: item.qty }) }}
In stock
Out of stock
Model: SM-IW86AHT
UHD 4K Display
The 4K Ultra HD display delivers incredible image quality with four times resolution higher than Full HD. Optimized for viewing distances both near and far the display allows your content to take center stage
Smooth Annotations
The line thickness of your annotations varies depending on pressure and speed, allowing you to achieve a realistic and natural handwriting experience.
Multi-Device Wireless Mirroring
Wirelessly project the displays of up to four smartphones, tablets, laptops, PCs or Macs. Using mobile devices you can mirror the display in both directions, and even take control of the touch screen. Mirroring via 5GHz allows for fast response, all without the need of external wires or transmitters.
BDTÂ 560,000.00 BDTÂ 565,000.00
Brand: SAMI
Model: SM-IW86AHT
Panel:
Screen Size: 86 inch
Touch Type: Infrared touch technology
Panel Type: TFT LCD Module with DLED Backlight
ouch Tool: Finger/Nontransparent Objects
Number of Touch: Up to 20 Point Multi-touch
Response Time: 8ms (over 90% Area), ≤10ms
Accuracy: ±1mm(over 90% Area)
Valid Touch: 2mm
Touch Heigh: ≤2.5mm
Anti-Light Interface: Anti-Dazzle Tempered Glass
Surface Hardness: 8H
Touch Resolution: 31767 × 32767
Resolution: 3840 (H) x 2160 (V), 4K UHD
Display Area: 1896mm (H) x 1067mm (W)
Aspect Ratio: 16:9
Brightness: 450 cd/m²(dyn.)
Color: 1.07 Billion (10 bits)
Viewing Angle: 178° (H); 178° (V)
Writing mode: Finger + Pen(attaches magnetically)
Backlight Life: ≥50,000 hrs
Refresh Rate: 60 Hz
Contrast Ratio: 1200:1 Typ
Dynamic Contrast Ratio : 5000:1 Dyn.
Display Life: 50,000
Audio:
Speaker Type: 2.0 Sound Channel, front end 15W x 2
AV Inputs: Front Inputs USB x 2, Rear Inputs, HDMI-In x 2, Audio In, USB x 2, RS232
OutputsTouch USB (Type B), Audio Out
Power:
Power Consumption: 200 W (typ.); 400 W (max.)
Standby Power Consumption: ≤0.5 W
Input Voltage: 100–240 VAC, 50/60 Hz
Mechanical
Dimension : 76.90" × 3.66" × 46.77"
Frame Size: U: 33.3 mm, L/R: 14.6 mm, D: 43.0 mm
Net Weight: 68 kg (149.92 lb)
Gross Weight: 82 kg (180.78 lb)
Environmental
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature: -10 °C to +50 °C (+14 °F to +122 °F)
Operating Humidity: 10%-90% (RH)
Storage Humidity: 10%-90% (RH)
Computer:
Android OS: Android 13.0
Processor: Core I5 10th Generation
Chip: SOC
RAM: 8GB
ROM: 64GB
PC system: Windows 11
CPU: Quad-Core A55
CPU Frequency: 2.4GHz
Memory: 8GB DDR4
SSD: 128GB SSD
Interface: USB 3.0 x 4, RJ45, WIFI
GPU: Mali G610 MP4 with 4K support
LAN: 2x RJ45 10 / 100 Mbps (Android)
Wi-Fi: Wi-Fi 5 24 GHz Integrated Wi-Fi 802 11 b/n/a/ac supports PEAP/EAP-GTC authentication protocol within 802
Wireless Access Point: WIFI 5, 2.4 GHz/5 GHz; Supports enabling Hotspot and Wi-Fi at the same time
Wi-Fi Hotspot: Wi-Fi 5, 2.4GHz and 5 GHz dual band, 802.11 ac/n
Bluetooth: Bluetooth 5.2
Sound Card: Realtek ALC897
HDMI Input/Output: 3× HDMI 2.0/1× HDMI 2.0
Display Port Input: 1× 1.2
BIOS: AMI UEFI BIOS
IR Receiver: Yes
I/O Ports: 1 x OPS, 4 x USB-A 3.0
Accessories Included: Remote Control with Battery, Power Cord, 2x Touch pen, Quick Start Guide, Touch Cable (USB to USB), Wall Mount
Certification: ISO, CE, Energy Star, ERP, ROHS, FCC, CBCA
Warranty:
Warranty Period: 1 Year
Technical Support: Life time
